Certified & Safe – Manufactured in accordance with ATEX Directive 2014/34/EU, ideally suited for extreme applications

Gentle on Cables & Strong – Thanks to integrated strain relief, high performance in daily use

Sophisticated Design – Slotted, conical grommets with special surface and outer geometry

Particularly Tight – Reliable protection against dust, gas, water, and dirt

Flexible – Inner diameter can be adjusted to the cable diameter

The EW-PA-EX cable protection conduits are made of specially modified polyamide 12 a high discharge capacity. The material is halogen, phosphor and cadmium-free.

EW-PA-EX cable protection conduits meet the electrostatic requirements for conductive materials when earthed. At the same time, they offer outstanding flexibility. With appropriate earthing they can be used in dust explosion hazardous areas of Zone 20, 21 and 22 as well as in gas explosion hazardous areas of Zone 0, 1 and 2 (independent of the explosion group of the existing gas).

These EW-PA-EX conduit properties make them the perfect choice for industrial handling systems and robotics applications and in all areas where antistatic (ESD protection) equipment is required (mining, refineries, chemical industry).

Leuze EX Protection solutions offer advanced sensor technology engineered for reliable operation in environments with explosive gases or dust, ensuring both safety and compliance with ATEX and IECEx standards. Available in various sensor formats, including photoelectric, retro-reflective, and safety light curtains, these devices provide accurate detection and robust performance, housed in protective metal casings for maximum durability. Leuze’s intrinsically safe designs keep processes efficient while safeguarding personnel and assets in hazardous areas.

The world's first safe 3D radar system, LBK, was developed for the monitoring of hazardous areas in harsh industrial environments. It detects the bodies of persons and in doing so monitors the protected area for access and presence. Using the controller, up to 6 sensors can be combined.

Advantages for you:

Reliable operation, even under harsh ambient conditions with, e.g., dirt, dust, smoke, and light

Flexible adaptation of the protected area to the application: determine the number and position of the sensors, configure the length and opening angle/width of the area.

Static objects in the protective field are permissible and do not result in shutdown of the safety outputs

Fast integration due to simple system design and controller with PROFIsafe or FSoE interface
